Page #29 background imageLoading...
Page #29 background image
- 29 -
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
A1 SAB31547201 S/W PackageM228WD EUROPE
A2 AKB33871401 Remote Controller Assembly19_22L
A21 MCK36759201 CoverMOLD ABS HF-380 MKJ339814 A
A3 EAD37992102 Power CordEAD37992102 LP-34A LS-
A4 130-013B "Battery,ManganeseR03( STC) 1.5V"
A5 3840TRL098A CardPRINTING EU MODEL BRAND WEE
A6 68509F0003A "Cable,AssemblyD-SUB TO D-SUB UL2"
A7 6852TAZ006P "Cable,AssemblyKCA-ST-3-0010 STER"
A8 EAD32701402 "Cable,AssemblyDC1DVISST30200B HD"
A9 MBM41461401 CardPRINTING OTHERS BRAND M228WD
C100 0CH5470K618 "Capacitor,Ceramic,Chip0402N470M5"
C1000 0CK475DD57A "Capacitor,Ceramic,ChipC2012X5R1A"
C1001 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C1007 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1007 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1009 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C101 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C1010 0CE476WC6DC "Capacitor,AL,ChipMVK5.0TP6.3VC47"
C1011 0CK104CK56A "Capacitor,Ceramic,Chip0603B104K5"
C1012 0CC680CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1013 0CC680CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1014 0CC680CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1015 0CC680CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1016 0CK104CK56A "Capacitor,Ceramic,Chip0603B104K5"
C1017 0CK104CK56A "Capacitor,Ceramic,Chip0603B104K5"
C1018 0CK104CK56A "Capacitor,Ceramic,Chip0603B104K5"
C102 0CE106WFKDC "Capacitor,AL,ChipMVK4.0TP16VC10M"
C103 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C104 0CK105CD56A "Capacitor,Ceramic,ChipC1608X7R1A"
C105 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C106 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1068 0CE107WF6DC "Capacitor,AL,ChipMVK6.3TP16VC100"
C107 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C108 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C109 0CK105CD56A "Capacitor,Ceramic,ChipC1608X7R1A"
C110 EAE32707901 "Capacitor,AL,Chip20SVP22M 22uF 2"
C1100 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1101 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1102 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1103 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1104 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1105 0CC101CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1106 0CC101CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C111 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1112 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1113 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C1114 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C112 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1120 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1121 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1123 0CE476WC6DC "Capacitor,AL,ChipMVK5.0TP6.3VC47"
C1126 0CE476WC6DC "Capacitor,AL,ChipMVK5.0TP6.3VC47"
C113 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C114 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C115 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C116 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C117 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C118 0CE106WFKDC "Capacitor,AL,ChipMVK4.0TP16VC10M"
C119 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C120 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1204 0CC221BKFAA "Capacitor,Ceramic,ChipC1005C0G1H"
C1205 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C1206 0CK102BK56A "Capacitor,Ceramic,Chip0402B102K5"
C1207 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C1208 0CK102BK56A "Capacitor,Ceramic,Chip0402B102K5"
C1209 0CC221BKFAA "Capacitor,Ceramic,ChipC1005C0G1H"
C121 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1210 0CC221BKFAA "Capacitor,Ceramic,ChipC1005C0G1H"
C1211 0CC331CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1215 0CC331CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1216 0CC331CK41A "Capacitor,Ceramic,ChipC1608C0G1H"
C1217 EAE32755801 "Capacitor,Ceramic,ChipCL31A106K5"
C122 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1225 EAE32755801 "Capacitor,Ceramic,ChipCL31A106K5"
C123 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1232 0CE107WF6DC "Capacitor,AL,ChipMVK6.3TP16VC100"
C1234 0CK102BK56A "Capacitor,Ceramic,Chip0402B102K5"
C1235 0CK102BK56A "Capacitor,Ceramic,Chip0402B102K5"
C1236 EAE32755801 "Capacitor,Ceramic,ChipCL31A106K5"
C1237 EAE32755801 "Capacitor,Ceramic,ChipCL31A106K5"
C1239 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C124 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1244 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C1246 0CK103BH56A "Capacitor,Ceramic,ChipC1005X7R1E"
C125 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C126 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C127 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C128 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C129 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C130 0CK104BF56A "Capacitor,Ceramic,ChipC1005X7R10"
C1300 0CK225DH94A "Capacitor,Ceramic,ChipC2012Y5V22"
C1301 0CE476WH6DC "Capacitor,AL,ChipMVK8.0TP25VC47M"
C1302 0CK474CH94A "Capacitor,Ceramic,Chip0603F474Z2"
C1303 0CK474CH94A "Capacitor,Ceramic,Chip0603F474Z2"
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
REPLACEMENT PARTS LIST
DATE: 2007. 09. 11.
CAPACITORs
