EXPLODED VIEW PARTS LIST

300

310

320

060

070

080

120

ABJ36436101

Cabinet Assembly,W1642 ... 16" -

MEY40926601

Knob, MOLD ABS HF-350 MAIN 5 key WX42 BLACK

MBG41956001

Button,Power, MOLD ABS WX42 translucent ABS power button + lens

400

ACQ36436201 Cover Assembly,Rear, W1642 ... 16" -

410

MDQ39062303 Frame, PRESS EGI 0.8 L177WSB EGI L177W Rear Frame LPL-HSD local

420

MGJ42000901 Plate,Shield, PRESS SPTE 0.3 LAMP SPTE -

430

MCK42615801 Cover, MOLD ABS HF-350 W1642 ABS Hinge body

440

MCK42615601 Cover, MOLD ABS HF-350 W1642 ABS HINGE COVER

910

MCK42001101 Cover, MOLD ABS W1642 ABS -

920

MCK42616001 Cover, MOLD ABS HF-350 W1642 ABS Base cover

020

EAJ42583301

LCD,Module-TFT, M156B1-L01 WXGA 15.6INCH 1366X768 250CD COLOR 65% 16/9 500:1 CMO15.6"W,TN,ZBD,Non-Glare,2CCFL,16.7M,Response time:8ms,Viewing Angle:90/45 CHI MEI OPT

EBR41617001 PCB Assembly, CONTROL T.T LM73A BAIKAL 3 19-INCH RD -

EBU43054601 Main Total Assembly, W1642 MSTAR ANALOG BRAND LM73B

Power Supply Assembly, FREE W1642 LCD Lianchang ------

6410TMW004A

6410TMW002B

Power Cord, UC,LP-45 & H05VV-F 0.75_3C, LS-60_1.87M_BLK LP-45 LS-60 1.87M - 250V 10A H05VV-F 3X0.75MM2 BLACK INMETRO N LONGWELL COMPANY

Power Cord, SP-305+IS-14 H05VV-F 3GX0.75mm2 CT-12_1.87M_BLK SP-305 IS-14 1.87M NONE 250V 15A H05VV-F 3X0.75MM2 BLACK INMETRO N I-SHENG ELECTRIC WIRE & CABLE CO.,

Description

Part No.

Ref. No.

* Note: Safety mark

EAY38422102
