- 12 -

8. DVI input (PC)-M198WA

No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz)

1 720*400 31.468 70.08 28.321

2 640*480 31.469 59.94 25.175

3 640*480 37.5 75 31.5

4 800*600 37.879 60.317 40.0

5 800*600 46.875 75.0 49.5

6 1024*768 48.363 60.0 65.0

7 1024*768 60.123 75.029 78.75

8 1152*864 67.500 75.000 108.0

9 1280*1024 63.981 60.02 108.0

10 1280*1024 79.976 75.035 135.0

11 1440*900 55.5 59.90 88.750

12 1440*900 55.935 59.887 106.50

No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed

1. 720*480 31.47 59.94 27.000 480P

2. 720*480 31.50 60.00 27.027 480P

3. 720*576 31.25 50.00 27.000 576P

4. 1280*720 37.5 50.00 74.250 720P

5. 1280*720 44.96 59.94 74.176 720P

6. 1280*720 45.00 60.00 74.250 720P

7. 1920*1080 33.72 59.94 74.176 1080i

8. 1920*1080 33.75 60.00 74.250 1080i

9. 1920*1080 28.125 50.00 74.250 1080i

7. RGB input ( DTV )

* M228WA
