No. Item Min Typ. Max Unit Remark
1. Type TFT Color LCD Module
2. Active Display area 410.4 (H) x 256.5 (V) mm
3. Outline dimension 427.2 (H) x 277.4 (V) x17.0 (D) mm Typ
4. Pixel pitch 0.285mm (H) x 0.285mm (V) x RGB mm
5. Color arrangement RGB vertical stripe
6. Color Depth 16.7M color
7. Electrical Interface LVDS
8. Surface Treatment Hard coating(3H) & Anti-glare(Haze 25)
9. Operating Mode Normally White
10. Back light Unit 4 CCFL (4 lamps)
11. R/T R.T : 1.3ms + R.T : 3.7ms Typ.
No. Item Specification Remark
1 Supported Sync. Type Separate Sync., Digital
2 Operating Frequency Analog Horizontal 28 ~ 83kHz
Vertical 56 ~ 75 Hz
Digital Horizontal 28 ~ 83kHz
Vertical 56 ~ 75 Hz
3 Resolution(M198WA) Analog Max. 1440 x 900 @ 75Hz
Recommend 1440 x 900 @ 60Hz
Digital Max. 1440 x 900 @ 60Hz
Recommend 1440 x 900 @ 60Hz
Resolution(M228WA) Analog Max. 1680 x 1050 @ 60Hz
Recommend 1680 x 1050 @ 60Hz
Digital Max. 1680 x 1050 @ 60Hz
Recommend 1680 x 1050 @ 60Hz
4 Input Voltage Voltage :100 - 240 Vac, 50 or 60Hz
5 Inrush Current Cold Start : 50 A Hot : 120 A
6 Operating Condition Sync (H/V) Video LED Wattage
Power S/W On
On mode
On/On Active Blue 60W Max.
On/On Active Blue 50W Typ.
Sleep mode
Off/On
Off Amber 1W
On/Off
Power S/W Off Off mode - Off Off 1W
7 MTBF 50,000 HRS with 90% Confidence level Lamp Life : 50,000 Hours(min)
8 Using Altitude 5,000 m (for Reliability) 3,000m(for FOS)
9 Operating Environment Temp : 10°C ~ 35°C
Humidity : 20% ~ 80%
10 Storage Environment Temp : -10°C ~ 60°C non condensing
Humidity : 5% ~ 90% non condensing
4.1.2 RGB/DVI
4-2. Module Specification(LPL LM190WX1-TLC1, P/N:EAJ36290801 (ZBD)) - M198WA
