LG FRIDGE - Installation checkup and finishing work

17
22. Insert the ventilation cover ⒔ into the rectangular hole on the front of the cabinet base.
23. Attach the gasket ⒕ as shown
in the figure. Attach it to the
opposite side from the hinge
side. If the gasket is to long,
cut it to the necessary length
required.
24. Insert the screw cap ⑮ as shown at the figure.
6. Procedure to install
5) Installation checkup and finishing work
1800mm
(Figure 19)
18
18
18
6
6
15
15
17
After securing screws,
install screw cap.
