9
The Basics
11. Laser Detection Auto-focus Detects the distance between the rear
camera lens and nearby objects using laser technology. This feature
helps the camera to focus quickly and accurately at short or long
distances.
NOTE Don't cover the Proximity Sensor and Laser Detection Auto-focus with a protection film,
pouch, or protection case not authorized by LG as they may cause the device to
malfunction.
12. Power/Lock Key Press to turn off the screen backlight and lock the
screen, or turn the screen backlight back on. Press and hold to turn the
phone on/off, restart it, or activate/deactivate Airplane mode.
13. NFC Touch Point Tap the back of your phone to an NFC tag or another
NFC compatible device in this location to transfer data between them.
14. Speaker Use to listen to audio (e.g., music, videos, sound clips,
speakerphone, etc.) from the rear speaker instead of the earpiece.
15. Volume Keys Press to adjust the ringer, the media volumes, or the
in-call volume during a call.
TIPS s With the screen backlight off (asleep), you can press and hold the
Volume
Down
Key
to activate the
Camera
app.
s With the screen backlight off (asleep), you can press and hold the
Volume
Up
Key
to access the QuickMemo+ app.
16. LED Flash Brightens up the captured image or recorded video when
you turn on the flash.
Top and Bottom View
USB/Charger
Port
Microphone
3.5mm
Headset Jack
Microphone
IR (Infrared)
LED
17. IR (Infrared) LED Uses infrared to communicate with devices using the
QuickRemote app.
18. Microphone Transmits your voice to the other caller. It's also used for
voice-activated functions.
