LG GC-B247SLUV User Manual

10
EN
Before Installation
Dimensions and
Clearances
Too small of a distance from adjacent items may
result in the degradation of freezing capability and
increased electricity costs. Allow over 50 mm of
clearance from each adjacent wall when installing
the appliance.
A
C
H
B
D E
F
G
- Size
A 912 mm
B 1790 mm
C 738 mm
D 615 mm
E 690 mm
F 738 mm
G 1180 mm
H 1750 mm
Ambient Temperature
• The appliance is designed to operate within
a limited range of ambient temperatures,
depending on the climate zone.
• The internal temperature could be affected
by the location of the appliance, the ambient
temperature, the frequency of door opening and
so on.
• The climate class can be found on the rating
label.
Climate Class
Ambient Temperature
Range ºC
SN (Extended
Temperate)
+10 - +32
N (Temperate) +16 - +32
ST (Subtropical) +16 - +38
T (Tropical) +16 - +43 / +10 - +43*
*Australia, India, Kenya
NOTE
• The appliances rated from SN to T are intended
to be used at an ambient temperature between
10 ºC and 43 ºC.
Accessories
*1:This feature is only available on some models.
a b
a
Spanner A*1
b
Spanner B*1
INSTALLATION

LG GC-B247SLUV Specifications

General

Noise level	- dB
Water dispenser	-
Total net capacity	626 L
Lamp type	LED
No Frost (fridge)	Yes
Fridge net capacity	406 L
Number of vegetable drawers	2
Fridge number of shelves/baskets	4
Freezer position	Side-placed
Freezing capacity	- kg/24h
Freezer net capacity	220 L
Storage time during power failure	- h
Product color	Platinum, Silver
Shelves material	Tempered glass
Appliance placement	Freestanding
Connected load	- W
Annual energy consumption	- kWh

Weight and Dimensions

Depth	738 mm
Width	912 mm
Height	1790 mm
Weight	113000 g
