9
Installation clearances
The location must be large enough to open
the washer door completely.
Washer dimensions
The following dimensions shown are for the minimum
spacing allowed.
Additional spacing should be considered for
installation and servicing.
• Additional clearances might be required for wall,
door, and floor moldings.
•
Additional spacing of 4"(10 cm) on back,
1"(2.5 cm) on all sides of the washer is
recommended to reduce noise transfer.
Companion appliance spacing should also be
considered.
Minimum installation spacing for
recessed area installation.
Front view
Side view
52 5/8"
133.7 cm
30 3/16"
(76.7cm)
30 3/16"
76.7 cm
52 5/8"
133.7 cm
30 3/16"
(76.7cm)
30 3/16"
76.7 cm
52 5/8"
133.7 cm
30 3/16"
(76.7cm)
30 3/16"
76.7 cm
