Inlet ValveMain PWB
Resistance
[k
]
Main
(1) ~ (2)
NA4 6
th
~
YL1 3
rd
0.8 ~ 1.2
Softener
(1) ~ (2)
NA4 2
nd
~
YL1 3
rd
0.8 ~ 1.2
Bleach
(1) ~ (2)
NA4 3
rd
~
YL1 3
rd
0.8 ~ 1.2
Hot
(1) ~ (2)
NA4 4
th
~
YL1 3
rd
0.8 ~ 1.2
tnioP kcehCmotpmyS
1. INLET VA LVE ERROR1.Check Electric Wiring.
2.Check Inlet valve's Resistance.
3.Check Inlet valve clogged.
4. Voltage of the inlet valve'sconnector.
-. Valve running : 120Vac ± 5%
Hot
Softener
Main
Bleach
NA4 YL1
