1. Disassemble theCONTROL PANELASSE MBLY
(Refer to page 38)
-Single model-
-Stack model-
2. Disassemble the
TOP PLATE
ASSEMBLY
(Refer to page 39)
3. Disassemble t
he
he clamps and hoses.
4.
Disassemble the bellows at the lower side of DISPENSE R
1. Disassemble theCONTROL PANELASSE MBLY
(Refer to page 38)
2. Disassemble the
T
OP
PL
P
OP PLATE
ASSEMBLY
(Refer to page 39)
3.
Disassemble the 4 connectors from the VALVES .
4. Disassemble the clamps and hoses.
5. Unscrew the2 screwsin the back.
Connector Color
ྙ
Blue Housing(OR-BK)
ྚ
White Housing (WH-BK)
ྛ
Blue Housing (GY-BK)
ྜ
Red Housing (BL-BK)
DISPENSER ASSEMBLY
Clamp
DISPENSER ASSEMBLY
Clamp
