LG GX500 Service Manual

- 10 -
LGE Internal Use Only Copyright © 2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
2. PERFORMANCE
GX500 Operational Description Revision A
LG Electronics 10/143 LGE Property
2.2 Technical specification
Item Description Specification
1
Frequency Band
GSM850
TX: 824 + 0.2 x n MHz
RX: 869 + 0.2 x n MHz ( n = 128 ~ 251 )
EGSM
TX: 890 + 0.2 x (n-1024) MHz
RX: 935 + 0.2 x (n-1024) MHz ( n = 975 ~ 1023 /1 ~ 124)
DCS1800
TX: 1710 + ( n-511 ) u 0.2 MHz (n = 512 a 885)
RX: TX + 95 MHz
PCS1900
TX: 1850.2 + ( n-512 ) u 0.2 MHz (n = 512 a 810)
RX: TX + 80MHz
2
Phase Error
RMS < 5 degrees
Peak < 20 degrees
3
Frequency Error < 0.1ppm
GSM850/EGSM
Level Power Toler. Level Power Toler.
5 33 dBm ±2dB 13 17 dBm ±3dB
6 31 dBm ±3dB 14 15 dBm ±3dB
7 29 dBm ±3dB 15 13 dBm ±3dB
8 27 dBm ±3dB 16 11 dBm ±5dB
9 25 dBm ±3dB 17 9 dBm ±5dB
10 23 dBm ±3dB 18 7 dBm ±5dB
11 21 dBm ±3dB 19 5 dBm ±5dB
12 19 dBm ±3dB
DCS1800/PCS1900
Level Power Toler. Level Power Toler.
0 30 dBm ±2dB 8 14 dBm ±3dB
1 28 dBm ±3dB 9 12 dBm ±4dB
2 26 dBm ±3dB 10 10 dBm ±4dB
3 24 dBm ±3dB 11 8 dBm ±4dB
4 22 dBm ±3dB 12 6 dBm ±4dB
5 20 dBm ±3dB 13 4 dBm ±4dB
6 18 dBm ±3dB 14 2 dBm ±5dB
4
Power Level
7 16 dBm ±3dB 15 0 dBm ±5dB
