79
Appendix
7
Appendix
Specifi cations
General
Power requirements:
AC 200-240 V, 50/ 60 Hz
Power consumption:
60 W
Dimensions (W x H x D):
Approx. 360 x 62.5 x 313 mm without foot
Net Weight (Approx.):
2.73 kg
Operating temperature:
41 °F to 95 °F (5 °C to 35 °C)
Operating humidity:
5 % to 90 %
Bus Power supply (USB):
DC 5V
500 mA
Inputs/ Outputs
VIDEO OUT:
1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
COMPONENT VIDEO OUT:
(Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1,
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
HDMI OUT (video/audio):
19 pin (HDMI standard, Type A, Version 1.3)
Analogue AUDIO IN:
1.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL 1/2):
3 V (p-p), Optical jack x 2
PORT. IN:
0.5 Vrms (3.5 mm stereo jack)
•
•
•
•
•
•
•
•
•
•
•
•
•
Tuner
FM Tuning Range:
87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplifi er
Power output (4 Ω), (PEAK)
Total 400 W
Front 125 W x 2
Sub-Woofer 150 W (Passive)
Power output (4 Ω), (RMS), THD 10 % (4 Ω/ 3 Ω)
Total 310 W
Front 90 W x 2
Sub-Woofer 120 W (Passive)
System
Laser:
Semiconductor laser
Wavelength: 405 nm / 650 nm
Signal system:
Standard NTSC/PAL colour TV system
Frequency response:
20 Hz to 20 kHz (48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio:
More than 80 dB
Total harmonic distortion:
0.05 % at 1 W
Dynamic range:
More than 85 dB
LAN port:
Ethernet jack x 1, 10BASE-T/100BASE-TX
•
•
•
•
•
•
•
•
•
•
