5. Supported video resolutions

5.1. HDMI Input (PC/DTV)

No. Resolution H-freq (kHz) V-freq (Hz) Pixel clock (MHz) Proposed

HDMI-PC

1 640*350 31.46 70.09 25.17 EGA

2 720*400 31.46 70.08 28.32 DOS

3 640*480 31.46 59.94 25.17 VESA(VGA)

4 800*600 37.87 60.31 40 VESA(SVGA)

5 1024*768 48.36 60.00 65 VESA(XGA)

6 1360*768 47.71 60.01 84.75 VESA(WXGA)

7 1152*864 54.34 60.05 80 VESA

8 1280*1024 63.98 60.02 109.00 SXGA

9 1920*1080 67.5 60 158.40 WUXGA(Reduced Blanking)

HDMI-DTV

1 640*480 31.46 59.94 25.12 SDTV 480P

2 640*480 31.5 60.00 25.12 SDTV 480P

3 720*480 31.47 59.94 27 SDTV 480P

4 720*480 31.5 60.00 27.02 SDTV 480P

5 720*576 31.25 50.00 27 SDTV 576P

6 1280*720 44.96 59.94 74.17 HDTV 720P

7 1280*720 45 60.00 74.25 HDTV 720P

8 1280*720 37.5 50.00 74.25 HDTV 720P

9 1920*1080i 28.12 50.00 74.25 HDTV 1080I

10 1920*1080i 33.72 59.94 74.17 HDTV 1080I

11 1920*1080i 33.75 60.00 74.25 HDTV 1080I

12 1920*1080p 26.97 23.97 63.29 HDTV 1080P

13 1920*1080p 27.00 24.00 63.36 HDTV 1080P

14 1920*1080p 33.71 29.97 79.120 HDTV 1080P

15 1920*1080p 33.75 30.00 79.20 HDTV 1080P

16 1920*1080p 56.25 50.00 148.5 HDTV 1080P

17 1920*1080p 67.43 59.94 148.35 HDTV 1080P

18 1920*1080p 67.5 60.00 148.50 HDTV 1080P
