LG HF85LA User Manual

- 4 -
Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes.
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This spec sheet is applied all of the DLP Projector with FZ91A
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
(1) Temperature: 25 °C ± 5 °C, CST: 40 °C ± 2 °C
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
: Standard input voltage (100~240V @ 50/60Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
(5) The receiver must be operated for about 30 minutes prior
to the adjustment
3. Test method
(1) Performance: LGE PROJECTOR test method followed
(2) Required other specification
-Safety : KCC, IEC, CE specification (EN55022 Class B),
CCC.
-EMC : KCC, IEC, CE specification (EN60950-1), CCC.
-Wireless: WIFI module, Bluetooth module – Korea,NA
4. Model General Specification
No Item
Specication
Remark
Min Typ Max Unit
1
Video input applicable
system
ATSC / NTSC HF85LA-KR only
ATSC /NTSC-M/64&256QAM HF85LA-NA only
2 Available channel
1) VHF : 02~13
2) UHF : 14~69
3) DTV : 02-69
4) CATV : 01~158(HF85LA-KR)
01~135(HF85LA-NA)
5) CADTV: 01~158(HF85LA-KR)
01~135(HF85LA -NA)
HF85LA-KR / HF85LA-NA only
3 Power DC 19V @ 7.37A (140W) Set only
4 Input Voltage AC 100 ~ 240(±10%)V, 50/ 60Hz
5 Market
Korea HF85LA-KR
Europe HF85LS-EU, HF85LSR-EU
Japan HF85LS-JP
Global HF85LG-GL
North America HF85LA-NA
6 Picture size FULLHD (1920 x 1080)
7 Aspect ratio 16:9 Panel Resolution
8 Operating Temperature 0 40 Deg
9 Operating Humidity 80 %
10 Storage Temperature -20 60 Deg
11 Storage Humidity 85 %

LG HF85LA Specifications

General

Brand	LG
Model	HF85LA
Category	Projector
Language	English
