LG HT1100BB - Specifications

Appendix 41
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D) 430 X 60 X 310 mm without foot
Net Weight (Approx.) 4.0 kg
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) DC 5 V
0
500 mA
Inputs/ Outputs
VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
COMPONENT VIDEO OUT
(Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector )
ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
PORT. IN 0.5Vrms (3.5 mm stereo jack)
Amplier
Stereo mode 180 W + 180 W (4 Ω at 1kHz)
Surround mode
Front 180 W + 180 W (4 Ω at 1 kHz)
Center 180 W (4 Ω at 1 kHz)
Surround 180 W + 180 W (4 Ω at 1 kHz)
Subwoofer 200 W (3 Ω at 60 Hz)
