19
Designs and specifications are subject to change without
prior notice.
Specifications
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 2.5 kg
External dimensions (W x H x D) 360 x 62 x 305 mm
Operating conditions Temperature 5°C to 35°C,
Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser,
wavelength 650 nm
Tuner FM
FM Tuning Range 87.50 - 108.00 MHz
FM Intermediate Frequency 10.7 MHz
Amplifier
Stereo mode 45 W + 45 W (4Ω at 1 kHz, THD 10 %)
Surround mode Front: 45 W + 45 W(THD 10 %)
Subwoofer*: 75 W (8Ω at 30 Hz, THD 10 %)
Speakers
Front Speaker Passive Subwoofer
Model SH23DD-F SH23DD-W
Type 1 Way 1 Speaker 1 Way 1 Speaker
Impedance 4 Ω 8 Ω
Rated Input Power 45 W 75 W
Max. Input Power 90 W 150 W
Net Dimensions (W x H x D)
99 x 114 x 86 mm 156 x 325 x 320 mm
Net Weight 0.38 kg 3.5 kg
