Contents
Hooking up the unit . . . . . . . . . . . . . . . . . . . . . . . . . .4
Attaching the speakers to the DVD receiver . . . . . . . .5
Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
OSD Initial language settings - Optional . . . . . . . . . . .7
Initial Setting the Area Code - Optional . . . . . . . . . . . .7
Adjust the settings . . . . . . . . . . . . . . . . . . . . . . . . .7-9
2.1 Speaker Setup . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting the sound mode . . . . . . . . . . . . . . . . . . . . . . .9
Displaying Disc Information . . . . . . . . . . . . . . . . . . .10
Playing a disc or file . . . . . . . . . . . . . . . . . . . . . .10-12
Viewing photo files . . . . . . . . . . . . . . . . . . . . . . . . . .12
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . .13
Listening to music from your USB device . . . . . . . . .14
Recording music from CD to your USB device . . . . .15
Listening to music from your portable player . . . . . . .15
Language Codes . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Area Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Types of Playable Discs . . . . . . . . . . . . . . . . . . . . . .18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Welcome to your new DVD Receiver
POWER: This unit operates on a mains supply of 200-240V~, 50/60Hz.
WIRING: This unit is supplied with a BSI 1363 approved 13 amp mains
plug, fused at 5 amp. When replacing the fuse always use a 5 amp BS
1362, BSI or ASTA approved type. Never use this plug with the fuse
cover omitted. To obtain a replacement fuse cover contact your dealer. If
the type of plug supplied is not suitable for the mains sockets in your
home, then the plug should be removed and a suitable type fitted.
Please refer to the wiring instructions below:
WARNING: A mains plug removed from the mains lead of this unit must
be destroyed. A mains plug with bared wires is hazardous if inserted in a
mains socket.
Do not connect either wire to the earth pin, marked with the letter E or
with the earth symbol or coloured green or green and yellow. If any
other plug is fitted, use a 5 amp fuse, either in the plug, or at the
distribution board.
IMPORTANT: The wires in this mains lead are coloured in accordance
with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in the
mains lead of this unit may not correspond with the coloured marking
identifying the terminals in your plug, proceed as follows: The wire which
is coloured blue must be connected to the terminal which is marked with
the letter N or coloured black. The wire which is coloured brown must be
connected to the terminal which is marked with the letter L or coloured
red.
