22
* Designs and specifications are subject to change without prior notice.
FM Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
FM Intermediate Frequency 10.7 MHz
AM Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
AM Intermediate Frequency 450 kHz
Power Supply Refer to main label
Power consumption Refer to main lable
0 x 3 x 30 mm
Net Weight (Approx.) 2.4 kg
Operating temperature: 5 °C to 35 °C, Operation status: Horizontal
Operating humidity 5 % to 85 %
External dimensions (W x H x D) 36 6 7
Stereo mode 45W + 45W (Rated Output Power 30W, 4? at 1 kHz, THD 10 %)
Surround mode Front: 45W + 45W (Rated Output Power 30W, THD 10 %)
Center* 45W
Surround* 45W + 45W (Rated Output Power 30W, 4? at 1 kHz, THD 10 %)
Tuner FM
Amplifier
Speaker
160 - 20, 000 Hz
82 dB/W (1m)
45 W
90 W
98 x 101 x 105mm
0.52kg
(SH32SD-SZ) (SH32SD-WZ)
8
65 - 1, 500 Hz
80 dB/W (1m)
75 W
150 W
181 x 351 x 278mm
3.4kg
Frequency Response
Sound Pressure Level
