LG HT302SD User Manual

9
Installation and Setup
Speaker System Connection
Connect the speaker wires the speaker terminals.
To obtain the best possible surround sound, adjust the
speaker parameters (volume, distance, etc.).
Notes:

Be sure to match the speaker wires to the
appropriate terminal on the components, + to + and
– to –. If the cables are reversed, the sound will be
distorted and will lack bass.

If you use front speakers with low maximum input
rating, adjust the volume carefully to avoid
excessive output on the speakers.

LG HT302SD Specifications

General

Equalizer	Yes
RMS rated power	300 W
Audio output channels	5.1 channels
Audio formats supported	MP3, WMA
FM band range	87.5 - 108 MHz
Disc types supported	CD-R, CD-RW, DVD-R
Optical disc player type	DVD recorder
USB version	2.0
Component video (YPbPr/YCbCr) out	1
