General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 10.6 kg
(unit: 2.7 kg, stand: 7.9 kg)
External dimensions (W x H x D) 380 x 1022 x 331 mm
Operating conditions Temperature 5°C to 35°C,
Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser,
wavelength 650 nm
Tuner FM
FM Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
FM Intermediate Frequency 10.7 MHz
Amplifier
Stereo mode 140 W + 140 W (4Ω at 1 kHz, THD 10 %)
Subwoofer*: 220 W (3Ω at 30 Hz, THD 10 %)
Speakers
Front active
Speaker Subwoofer
Type 2 Way 3 Speaker 1Way1Speaker
Impedance 4 Ω 3 Ω
Rated Input Power 140 W -
Max. Input Power 280 W -
Net Dimensions (W x H x D)
300 x 1260 x 285 mm 245 x 415 x 435 mm
Net Weight 6.5 kg 13.2 kg
Designs and specifications are subject to change without
prior notice.
Specifications
