SPECIFICATIONS
GENERAL
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 4 kg
External dimensions (W x H x D) 430 x 70 x 305 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
CD/DVD
Signal system PAL 625/50, NTSC 525/60
Frequency response (audio)
Signal-to-noise ratio (audio) More than 75 dB (1 kHz, NOP - 6 dB, 20 kHz LPF/A-Filter)
Dynamic range (audio) More than 70 dB
Harmonic distortion (audio) 0.5 % (1 kHz, at 1W position) (20 kHz LPF)
VIDEO
Video input 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
Video output 1.0 V (p-p), 75 Ω, negative sync., RCA jack x 1
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, negative sync, RCA jack x 1
(PB)/(PR) 0.7 V (p-p), 75 Ω, RCA jack x 1
TUNER
FM
Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
Intermediate Frequency 10.7 MHz
Signal-to Noise Ratio 60 dB (Mono)
Frequency Response
AM [MW]
Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
Intermediate Frequency 450 kHz
AMPLIFIER
Stereo mode 100W + 100W (4 Ω at 1 kHz, THD 10 %)
Surround mode Front: 100W + 100W (THD 10 %)
Center*: 100W
Surround*: 100W + 100W (4 Ω at 1 kHz, THD 10 %)
Subwoofer*: 200W (3 Ω THD 10 %)
Inputs AUDIO IN, OPTICAL IN
Outputs MONITOR OUT, COMPONENT VIDEO OUT
SPEAKERS
Front/Rear Speaker Center speaker Passive Subwoofer
(SH72TZ-S) (SH72TZ-C) (SH72TZ-W)
Type 2 Way 2 Speaker 2 Way 2 Speaker 1 Way 1 Speaker
Impedance 4 Ω 4 Ω 3 Ω
Frequency Response 100 - 20,000 Hz 100 - 20,000 Hz 40 - 1,000 Hz
Sound Pressure Level 82 dB/W (1m) 82 dB/W (1m) 80 dB/W (1m)
Rated Input Power 100 W 100 W 200 W
Max. Input Power 200 W 200 W 400 W
Net Dimensions 300 x 1277 x 300 mm 430 x 107 x 83 mm 165 x 422 x 415 mm
(W x H x D)
Net Weight 4.11 kg 1.12 kg 7.6 kg
(* Depending on the sound mode
settings and the source, there may
be no sound output.)
