Hooking up the unit Main Unit
1 Power
Turns the unit on and off.
2 DVD/CD Disc Drawer
3 Open/Close
4 Play
5 Pause
6 Stop
7Tuning (-/+), Skip/ Search
8 Volume
Controls the volume when using any function.
9 PORT. (Portable) IN port
You can enjoy music from portable device on your unit.
10 USB port
You can play video, image and sound files by connecting the USB
device.
7
Digital Audio in connection
Connect the unit’s OPTICAL
IN jack to the optical out to
jack on your TV (or Digital
Device etc.)
12 3 45678
10 9
