24
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 3.9 kg
External dimensions (W x H x D) 430 x 73 x 305 mm
Operating conditions Temperature 5°C to 35°C,
Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser,
wavelength 650 nm
Tuner FM/AM [MW]
FM Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
FM Intermediate Frequency 10.7 MHz
AM Tuning Range 522 - 1,620 kHz or 520 - 1,720 kHz
AM Intermediate Frequency 450 kHz
Amplifier
Stereo mode 155 W + 155 W (4Ω at 1 kHz, THD 10 %)
Surround mode Front: 155 W + 155 W (THD 10 %) C e n t e r * : 155 W
Surround*: 155 W + 155 W
(4Ω at 1 kHz, THD 10 %)
Subwoofer*: 225 W (3Ω at 30 Hz, THD 10 %)
Speakers
Front/Rear Center Passive
Speaker speaker Subwoofer
Type 1 Way 1 Speaker 1 Way 1 Speaker 1Way1Speaker
Impedance 4 Ω 4 Ω 3 Ω
Rated Input Power 155 W 155 W 225 W
Max. Input Power 310 W 310 W 450 W
Net Dimensions (W x H x D)
98 x 226 x 90 mm 360 x 106 x 104 mm 161 x 401 x 383mm
Net Weight 0.8 kg 1.0 kg 5.8 kg
Designs and specifications are subject to change without
pior notice.
