Installation
3
3. Draw the speaker wire through the inside of
the pole and also through the hole on the
bottom of the speaker.
Step 3
Speaker
Pole
Base
Screw
Cable
4. Attach the speaker to the pole, the secure
the connection with a supplied screw.
Step 4
Speaker
Pole
Base
Screw
Cable
5. Connect the speaker wire to the terminal
on the speaker.
Make sure the wire marked black goes in
to the terminal marked “–” (minus) and the
other wire goes in to the terminal marked
“+” (plus).
Step 5
Speaker
Pole
Base
Screw
Cable
CAUTION
Be careful that the speaker
should not fall down.
Otherwise it may result in the
speaker malfunctioning and
causing personal injury and/
or property damage.
