29
310 419342253670R C SMD(0805) Y5V 2.2uF/25V Z RoHS 2 C507,C511,
320 419311040060R C SMD(0603) X7R 0.1uF/50V K RoHS 1 C821,
330 419316830060R C SMD (0603) X7R 0.068uF 50V,K RoHS 1 C510,
340 419316810070R C SMD(0805) X7R 680PF/50V K,RoHS 2 C523,C530,
350 419304710560R C SMD(0603) NPO 470PF/50V,J,RoHS 1 C529,
360 419311020060R C SMD(0603) X7R 1000PF/50V K RoHS 1 C504,
370 419314720060R C SMD(0603) X7R 4700PF/50V K RoHS 1 C506,
380 419312220060R C SMD(0603) X7R 2200PF/50V K RoHS 4 C501,C502,C513,C514,
390 419311030060R C SMD(0603) X7R 0.01uF/50V K RoHS 1 C505,
400 411020046090R DIO 1N4148W 75V/0.15A(PEC)RoHS SOD-123 0
400 411023004021R DIO SN4148-LF 75V/0.15A SMD 1206 (FEC)Ro 1 D506,
410 411020026390R DIO BAV99,SOT-23(INFINEON)RoHS 0
410 411020026020R DIO BAV99-LF 350mW 70V SOT-23 (FEC)RoHS 0
410 411020026210R DIO BAV99 350mW 70V SOT-23(PHI RoHS 2 D501,D502,
420 411020047020R DIO BAV70-LF 70V SOT23 (FEC) RoHS 0
420 411020047210R DIO BAV70 85V SOT23 (PHILIPS) RoHS 2 D503,D504,
430 411020068090R DIO BAW56 75V SOT-23(PANJIT)RoHS 0
430 411020068020R DIO BAW56 70V SOT-23(FRONTIER)RoHS 0
430 411020068210R DIO BAW56 85V SOT-23(PHILIPS)RoHS 1 D505,
440 412000455630R IC OZ9938GN SOIC16(O2 MICRO)RoHS 1 IC501,
450 419313330060R C SMD(0603) X7R 0.033uF/50V K ROHS 2 C516,C512,
460 790621410600R PCBA,PWR&INV./B,AI,LE1730-6E0 1
470 414916200010R
RES SMD (0603) 200Ω F,RT RoHS
1 R509,
480 414916100210R
RES SMD (0603) 10KΩ F,RT RoHS
1 R534,
500 419312230060R C SMD(0603) X7R 0.022uF/50V K RoHS 1 C508,
510 506140005700R LABEL,BARCODE,BLANK,33x7mm, ROHS,FOR PCB 1
520 411150391950R ZENER 9.1V MTZS05-9.1-G SOD-123 (MITSUBI 0
520 411131591952R ZENER 9.1V 0.5W DDZ9V1C-F,SOD1 23(DIODES 0
520 411100991920R ZENER 9.1V MMSZ5239A SOD123(PE C)RoHS 1 ZD805,
ITEM P/N Description Usage Location
790621410600R PCBA,PWR&INV./B,AI,LE1730-6E0
10 790621450600R PCBA,PWR&INV./B,AI/A, LE1730-6E0 1
20 790621460600R PCBA,PWR&INV./B,AI/R, LE1730-6E0 1
ITEM P/N Description Usage Location
790621450600R PCBA,PWR&INV./B,AI/A, LE1730-6E0
10 415130680540R
RES CF 1/2W 68
Ω
J,AT RoHS REV:A
1 R804,
20 415340101540R
RES MOF 1W 100Ω J,AT MINI RoHS
1 R828,
30 411030003040R DIO FR103 200V/1A DO-41(MOSPEC RoHS 0
30 411020052020R DIO A02-LF 200V/1A R1(FEC)RoHS 1 D806,
40 411020048090R DIO 1N4148-35 75V/0.15A,DO35(P EC)RoHS 0
40 411022003020R DIO 1N4148-LF 75V/0.15A AT (FEC)RoHS 0
40 411022003210R DIO 1N4148 75V/0.2A AT (PHIL) RoHS 1 D809,
50 411032006020R DIO FR10-10-LF 1000V/1A AT(FRO NTIER)RoH 0
50 411020055330R DIO MUR1100ERL AXIAL LEAD(ON) RoHS 1 D804,
60 411020050010R DIO P6KE150A,DO-15AT,(TSC)RoHS 0
60 411020050020R DIO P6KE150A-LF AT(FRONTIER) RoHS 0
60 411020050090R DIO P6KE150A,DO-15,AT(PANJIT)RoHS 1 ZD802,
70 432002200160R BEAD CORE BF30TA-3.5x9x0.8 AT 1 B801,
