LG L1718S-BN - - 17" LCD Monitor

30
80 415030105540R
RES CF 1/2W 1MΩ J,AT MINI RoHS
2 R820,R821,
90 414030330540R
RES FSM 1/2W 33Ω J,AT MINI,RoHS
4 R506,R508,R532,R533,
100 414870305540R
RES MG HV 1/2Ws 3MΩ 3KV J,AT RoHS
2 R501,R503,
110 430405000000R JMPR ROLL/KG D=0.6mm,AT,RoHS 7.5MM 364 J502,J507,J510,J516,J804
,J805,J809,
120 430405000000R JMPR ROLL/KG D=0.6mm,AT,RoHS 10MM 312 J503,J505,J514,J801,J803
,J808,
130 430405000000R JMPR ROLL/KG D=0.6mm,AT,RoHS 12.5MM 208 J508,J513,J515,J810,
140 430405000000R JMPR ROLL/KG D=0.6mm,AT,RoHS 15MM 208 J501,J512,J802,J511,
150 430405000000R JMPR ROLL/KG D=0.6mm,AT,RoHS 17.5MM 104 J506,J509,
160 700000000100R ASSY,PCB&RIVENT,LE1730 1
170 415020330540R
RES CF 1/4W 33Ω J,AT MINI RoHS
1 R521,
180 414020689540R
RES FSM 1/4W 6.8Ω J AT MINI,RoHS
1 R812,
ITEM P/N Description Usage Location
790621460600R PCBA,PWR&INV./B,AI/R, LE1730-6E0
10 418147038530R CAP CD NPO 47pF 1KV J,VT RoHS 1 C813,
20 418210227030R CAP CD X7R 1000pF 500V K VT RoHS 2 C802,C811,
30 419111040030R CAP MTL X7R 0.1uF 50V K,VT, RoHS 2 C817,C822,
40 420264700230R
CAP SH 47uF 25V M,125℃,VT, 6.3x11,RoHS
4 C814,C815,C818,C819,
50 410072013150R XSTR UTC2SC1815L-GR NPN TO92 (UTC)RoHS 0
50 410072013370R XSTR 2SC1815-GR (T2SPF.T) VT (TOSHIBA)Ro 0
50 410072013210R XSTR 2PC1815GR*I VT (PHILIPS) RoHS REV: 1 Q802,
60 412022002240R IC KA431AZ 1%,VT (FAIRCHILD) RoHS 0
60 412022002300R IC AP431VL TO-92 1% VT (ATC) RoHS 0
60 412022002830R IC AS431 TO-92 VT(A1SEMI)RoHS 0
60 412022002840R IC TL431ACLPG TO-92 1%,VT(ON)RoHS 1 IC803,
70 416231041530R CAP MEB 0.1uF 100V J,(RSB),VT RSBEC3100D 1 C816,
80 420424710260R
CAP SD 470uF/25V M 105
℃
ST 10x16,RoHS
1 C810,
90 420421510330R
CAP SD 150uF 35V M,105℃ VT 8x12 RoHS
2 C509,C522,
ITEM P/N Description Usage Location
700000000100R ASSY,PCB&RIVENT,LE1730
10 490621400100R PCB,PWR&INV./B, LE1730-XE0 1
20 512006000500R
RIVET,
Φ
3.0x
Φ
1.6x3.0mm
6 M3,M4,M5,M6,M7,M8,
30 512006000600R
RIVET,Φ 4.1xΦ 2.2x3.0mm
2 M1,M2,
KEYPAD
ITEM P/N Description Usage Location
790621500000R PCBA,KEYPAD BOARD, LE1730
10 430300300050R HRN ASS'Y 3P 130mm UL1007#28,RoHS 1 CN102,
20 430638080020R WFR. 8P 1.5mm R/A S8B-ZR RoHS JST 1 CN101,
30 430602980120R SW TACT 160gf 1P,H=4.3mm,DIP SFKHHAL2420 5 SW101,SW102,SW103,S
W104,SW105,
40 490621500100R PCB,KEY PAD, LE1730 1
50 511130001200R SOLDER BAR,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge0 0.48254
60 511130000300R SOLDER WIRE,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge 0.0345
70 511140000701R FLUX Grade 0.812±0.010 1.53295
