LG L1752S User Manual

A9
On Screen Display (OSD) Control Adjustment
Screen Adjustment
Making adjustments to the image size, position and operating parameters of
the display is quick and easy with the On Screen Display Control system.
A short example is given below to familiarize you with the use of the controls.
The following section is an outline of the available adjustments and selections
you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the MENU Button, then the main menu of the OSD appears.
To access a control, use the or Buttons. When the icon you want
becomes highlighted, press the AUTO/SET Button.
Use the / Buttons to adjust the image to the desired level. Use the
AUTO/SET Button to select other sub-menu items.
Push the MENU Button once to return to the main menu to select another
function. Push the MENU Button twice to exit from the OSD.
NOTE
Allow the display to stabilize for at least 30 minutes before making image adjustments.

LG L1752S Specifications

General

Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	TCO'03, UL, CUL, TUV-GS, SEMCO, FCC-B, CE, EPA Energy Star
Product color	Silver
Market positioning	-
USB Type-A downstream ports quantity	0
Plug and Play	Yes
Power consumption (standby)	1 W
Power consumption (typical)	37 W
Package weight	6800 g

Weight and Dimensions

Weight (without stand)	4600 g
