LG L1752S User Manual

On Screen Display(OSD) Selection and Adjustment
A14
Icons
Menu Name
Sub-menu Name
Main menu Sub menu Description
To adjust the USER sub-menu function,
Press the SET Button
MOVIE
TEXT
NORMAL
USER
When you execute F-ENGINE, two tones will appear
on the screen as shown. The applied screen will
appear on the left side, whereas the non-applied
screen will appear on the right side.Touch the SET
button to use the adjusted screen.
FLATRON F-ENGINE Screen when applied Screen when not applied
The OSD screen will appear when you touch the button on the
right side of the monitor.
TEXT : For text images (Word processing etc.)
Select the sub-menu using the SET button
and save the YES value using the buttons.
SAVE
MOVIE : For animation images in videos or movies
This is under normal operating conditions.
This feature lets you easily select the best desired
image condition optimized to the environment
(ambient illumination, image types etc).
User
You can manually adjust brightness, ACE or RCM.
You can save or restore the adjusted value even
when using a different environment setting.
...
(Brightness): Adjusts screen brightness.
...
ACE (Adaptive Clarity Enhancer) : Selects the clarity mode.
...
RCM(Real Color Management): Selects the color mode.
Not applied
Green enhance
Flesh tone
Color Enhance
0
1
2
3

LG L1752S Specifications

General

Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	TCO'03, UL, CUL, TUV-GS, SEMCO, FCC-B, CE, EPA Energy Star
Product color	Silver
Market positioning	-
USB Type-A downstream ports quantity	0
Plug and Play	Yes
Power consumption (standby)	1 W
Power consumption (typical)	37 W
Package weight	6800 g

Weight and Dimensions

Weight (without stand)	4600 g
