LG LAP240 - System Part - Led; System Part - Micom; Waveforms of Major Check Point

3-13
WAVEFORMS OF MAJOR CHECK POINT
1. SYSTEM PART - MICOM 2. SYSTEM PART - LED
ZUZ}htpjvt
slkylk
Figure 1.
IC100 R5F100GEAFB X-TAL 20 MHz
Figure 2.
IC100 R5F100GEAFB LED Control port
1
2
3
2
3
1
