15INSTALLATION
ENGLISH
Preparing Dishwasher
Removable Rear Plastic Shipping
Brace
The rear shipping brace can be removed if additional
clearance is needed when installing the dishwasher
under a low countertop.
NOTE
• Do not pull or lift the dishwasher using the handle;
doing so can damage the door and hinges. Open
the door and grab the body frame and the top front
opening of the tub to move or lift the dishwasher.
NOTE
• Do not push the door of the dishwasher with knees.
Removing Lower Cover
1
Remove the two screws attaching the lower
cover to the dishwasher.
2
Remove the lower cover from the base.
3
Remove the insulation pad from behind the
access panel.
CAUTION
• If at any time the dishwasher is laid on its back,
take care not to damage the drain hose.
NOTE
• Make sure that the lower cover replaces in the last
step.
To Next Page
