12. EXPLODED VIEW & REPLACEMENT PART LIST
- 277 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
4 EBR01
PCB
Assembly,Flexible
EBR76103902 LGE960.AVD2BK 1.1 Flexible F,27
5 EBR070100
PCB Assembly
Flexible,Insert
EBR76453601 LGE960.AUSGBK 1.2 Flexible
5 EBR070400
PCB Assembly
Flexible,SMT
EBR76027001 TITO2-C2.AZZZZZ 1.0 Flexible
6 EBR070200
PCB Assembly
Flexible,SMT
Bottom
EBR76027101 TITO2-C2.AZZZZZ 1.0 Flexible
7
C204
C205
Capacitor
Ceramic,Chip
ECCH0009104
C0603C0G1H330JT00NN 33pF 5% 50V C0G -
55TO+125C 0603 R/TP - TDK CORPORATION
7 CN203 Connector,I/O EAG63293501
GU07C-5P-E2000 5P 0.65MM ANGLE
RECEPTACLE DIP R/TP MHL MUSB IO LS Mtron
Ltd.
7 L100
Inductor
Multilayer,Chip
ELCH0001402
LL1005-FHL18NJ 18NH 5% - 300mA 0.6OHM
2.8GHZ 10 SHIELD NONE 1.0X0.5X0.5MM R/TP
TOKO, INC.
7 SW201 Connector,RF ENWY0003901
U.FL-R-SMT(10) 1.90MM STRAIGHT SOCKET
SMD T/REEL CU 50OHM 300mDB HIROSE
KOREA CO.,LTD
7 C209
Capacitor
Ceramic,Chip
ECCH0001001
C1005C0G1H6R8CT000F 6.8pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
7 C212
Capacitor
Ceramic,Chip
ECZH0000813
C1005C0G1H101JT 100pF 5% 50V C0G -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 EBR070300
PCB Assembly
Flexible,SMT Top
EBR76027301 TITO2-C2.AZZZZZ 1.0 Flexible
7 EAX010700 PCB,Flexible EAX64983201 LGE960.AVD2BK 1.0 POLYI Multi 6 0.3 Flexible
7
D202
D203
D204
ZD200
ZD201
ZD202
ZD205
Diode,TVS EAH61693001
uClamp0541Z 5V 6V min 12V 2A 30W
SLP0603P2X3 R/TP 2P 1 SEMTECH
INTERNATIONAL AG
7 MIC200
Microphone
Condenser
SUMY0010616
SUMY0010616 FPCB,dB,1.1TO10V, KNOWLES
ACOUSTICS
