12. EXPLODED VIEW & REPLACEMENT PART LIST
- 278 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
7 D205 Diode,TVS EAH61933401
PESD12VS1UB 12V 14.7V min. 35V 5A 180W
SOD523 R/TP 2P 1 NXP Semiconductors
7 CN201 Connector,BtoB ENBY0040201
GB042-34P-H10-E3000 34P 0.4MM STRAIGHT
PLUG SMD R/TP 1M - LS Mtron Ltd.
7
C204
C205
Capacitor
Ceramic,Chip
ECCH0009104
C0603C0G1H330JT00NN 33pF 5% 50V C0G -
55TO+125C 0603 R/TP - TDK CORPORATION
7
R200
R201
R202
Resistor,Chip ERHY0009501
MCR006YZPJ000 0OHM 5% 1/20W 0603 R/TP -
ROHM.
7 R204 Resistor,Chip ERHZ0000401
MCR01MZSJ000 0OHM 5% 1/16W 1005 R/TP -
ROHM.
7 FL200 Filter,EMI/Power SFEY0015301
NFM18PC104R1C3 ESD/EMI 0HZ 0.1uF 0H SMD
R/TP MURATA MANUFACTURING CO.,LTD.
7 C202
Capacitor
Ceramic,Chip
EAE62286801
CL03A104KP3NNNC 0.0000001F 10% 10V X5R -
55TO+85C 0603 R/TP 0.3 - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
7 LD200 LED,Array EAV61493701
CL-505S-X-SD-T RED/GREEN/BLUE RED :
1.35~2.35, GREEN : 2.3~3.0, BLUE : 2.3~3.0 RED:
30, GREEN/BLUE : 20 RED : 7.5~30, GREEN :
60~200, BLUE : 15~46 - 125mW 1x1x0.25T R/TP
4P - CITIZEN ELECTRONICS CO.,LTD.
4 EAN090500 PIFA Antenna,RF EAA62947101
PWMD-L201A DUAL -5DB 5:1 FPCB Type - NFC
Tape LG INNOTEK CO., LTD
42
4 EAA030101
PIFA
Antenna,Multiple
EAA62926301
ACB-00146 MULTI -5DB 5:1 FPCB Type - LTE
Tape MOBITECH CORPORATION
44
4 EAA030100
PIFA
Antenna,Multiple
EAA62926201
ACB-00147 MULTI -5DB 5:1 FPCB Type - MRD
Tape MOBITECH CORPORATION
43
4 EAU00 Motor,DC EAU61847901
WHVM-1030QPFS 2V 40mA 0A 12KRPM 0RPM
60mSEC 0GF.CM 17OHM WOOSUNG G&T
CO.,LTD
37
4 EAB01 Receiver EAB62868701
RS071225HF01N 50mW 32OHM 110DB
300HZTO3.4KHZ FPCB - BSE CO., LTD.
36
3 EBR02
PCB
Assembly,Main
EBR74340202 LGE960.AUSGBK 1.2 Main L,32
