12. EXPLODED VIEW & REPLACEMENT PART LIST
- 279 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
4 EBR071800
PCB Assembly
Main,SMT
EBR74340302 LGE960.AUSGBK 1.4 Main
5 EBR071700
PCB Assembly
Main,SMT Top
EBR74340402 LGE960.AUSGBK 1.4 Main
6 R1107 Resistor,Chip ERHZ0000235
MCR01MZP5F2000 200OHM 1% 1/16W 1005 R/TP
- ROHM.
6
L9002
L9003
Inductor,Wire
Wound,Chip
EAP62266701
0603HL-331XJRC 330NH 5% - 330mA - - 0.97OHM
420HZ 13 SHIELD 1.8X1.19X0.94 mm - R/TP
COILCRAFT SINGAPORE PTE LTD.
6 U11009 IC,Power Amplifier EAN62404201
ACPM-5505-TR1 3.2V to 4.2V 0 0 0W 0W 0 10
SMD R/TP 10P WCDMA Band5, 2mode, with CPL,
3*3*0.9mm AVAGO TECHNOLOGIES
INTERNATIONAL SALES PTE. LIMITED
6 C1108
Capacitor
Ceramic,Chip
ECCH0000145
MCH155CN152KK 1.5nF 10% 50V X7R -
55TO+125C 1005 R/TP - ROHM Semiconductor
KOREA CORPORATION
6 R1109 Resistor,Chip ERHZ0000327
MCR01MZSF1800 180OHM 1% 1/16W 1005 R/TP
- ROHM.
6 EAX010000 PCB,Main EAX65044001
LGE960.AVD2BK 1.0 FR-4 Any Layer 12 0.8mm
Main
