12. EXPLODED VIEW & REPLACEMENT PART LIST
- 284 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
SC7001
SC7002
SC7003
SC7004
SC7005
SC7006
SC7007
SC7008
SC7009
SC7010
SC7012
SC7016
SC7017
SC7018
SC7019
SC7020
Connector
Terminal Block
ENZY0026801
25SMT-3645-34 1P - STRAIGHT SMD R/TP -
W.L.GORE & ASSOCIATES (HK) LTD.
6
C23037
C23038
C23039
C23040
C23041
C23052
Capacitor
Ceramic,Chip
ECCH0017601
CL05A475MQ5NRNC 4.7uF 20% 6.3V X5R -
55TO+85C 1005 R/TP 0.5MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
L11075
L11078
Inductor
Multilayer,Chip
EAP62227701
LG HK 0603 8N2J-T 8.2NH 5% - 230mA - -
0.45OHM 3.4GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6 R23002 Resistor,Chip ERHZ0000701
MCR03EZP5J000 0OHM 5% 1/10W 1608 R/TP -
ROHM.
6 D7004 Diode,Switching EDSY0018101
RB521CS-30GJT2R 350mV 30V 100mA 0A 0SEC
200mW VMN2 R/TP 2P 1 ROHM.
6
R13010
R21014
R21028
R22002
R23008
R23014
R5005
R5008
R7014
R7018
PCB ASSY
MAIN
PAD OPEN
SAFO0000401 AX3100 ATL SV_SHIPBACK,MAIN,A,0OHM DNI
