12. EXPLODED VIEW & REPLACEMENT PART LIST
- 285 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C15010
C15012
C15013
C15014
C23027
C23029
C23030
C23033
Capacitor
Ceramic,Chip
ECCH0017501
CL10A226MQ8NRNE 22uF 20% 6.3V X5R -
55TO+85C 1608 R/TP 0.8MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
L23001
L23002
L23006
L23007
L23008
L24001
L24002
Inductor,Wire
Wound,Chip
EAP62266501
MAMK2520T1R0M 1UH 20% - 2.7A 3.1 2.7
0.059OHM - - SHIELD 2.5X2.0X1.2MM - R/TP
TAIYO YUDEN CO.,LTD
6
C1105
C1106
C1109
Capacitor
Ceramic,Chip
EAE62966901
CL10B104KB8NNNC_ 100nF -10TO+10% 50V X7R
-55TO+125C 1608 R/TP 0.8 L:1.6+-0.1 W:0.8+-0.1
T:0.8+-0.1 SAMSUNG ELECTRO-MECHANICS
CO., LTD.
6
C5006
C5010
C5018
C9031
Capacitor
Ceramic,Chip
EAE62762301
CL03A105MP3NSNC 1uF 20% 10V X5R -
55TO+85C 0603 R/TP 0.33 MM - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 U9002 IC,NFC EAN62446601
BCM20793SKML1G 4.0x4.5x0.85 QFN-34L PKG
QFN R/TP 34P BROADCOM ASIA DISTRIBUTION
PTE LTD
6 ZD6002 Diode,TVS EDTY0012501
UCLAMP3311T.TCT 3.3V 3.5V min. 6.5V 5A -
SLP1006P2T R/TP 2P 1 SEMTECH
CORPORATION
6 C11058
Inductor
Multilayer,Chip
ELCH0001420
LL1005-FHL3N9S_ 3.9NH 0.3NH - 300mA
0.18OHM 7.4GHZ 8 SHIELD NONE
1.0X0.5X0.5MM R/TP TOKO, INC.
6 L11027
Capacitor
Ceramic,Chip
ECCH0009212
GRM0335C1E4R7C 4.7pF 0.25PF 25V X7R -
55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 L11041
Inductor
Multilayer,Chip
EAP62227301
LG HK 0603 2N2S-T 2.2NH 0.3NH - 360mA - -
0.19OHM 8.8GHZ 4 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6
ZD6003
ZD6005
Diode,TVS EAH61533301
RCLAMP0521PA.TCT 5V 6V min. / 9.3V typ. / 11V
max. 15V 4A - SLP1006P2 R/TP 2P 1 SEMTECH
INTERNATIONAL AG
