12. EXPLODED VIEW & REPLACEMENT PART LIST
- 286 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
R21001
R21004
R21009
R21010
Resistor,Chip ERHY0009522
MCR006YZPJ332 3.3KOHM 5% 1/20W 0603 R/TP
- ROHM.
6
C7016
C7017
Capacitor
Ceramic,Chip
ECCH0009514
MCH032A(AN)100DK 10pF 0.5PF 25V X7R -
55TO+125C 0603 R/TP - ROHM.
6
C21003
C5003
C7018
Capacitor
Ceramic,Chip
EAE62461701
RM JMK042 BJ104MC-FW 100nF 20% 6.3V X5R -
55TO+85C 0402 R/TP 0.22T max. TAIYO YUDEN
CO.,LTD
6
C1100
C1110
Capacitor
Ceramic,Chip
EAE62685201
C1005X5R1E104K 0.1uF 10% 25V X5R -
55TO+85C 1005 R/TP 0.55T max. TDK KOREA
COOPERATION
6
C15017
C15033
Capacitor
Ceramic,Chip
ECCH0000182
GRM155R61A104K 0.1uF 10% 10V X5R -
55TO+85C 1005 R/TP - MURATA
MANUFACTURING CO.,LTD.
6
C13002
C13003
C23064
C5007
C5011
Capacitor
Ceramic,Chip
ECCH0009101
C0603X5R0J104KT00NN 0.1uF 10% 6.3V X5R -
55TO+85C 0603 R/TP - TDK CORPORATION
6 C11123
Capacitor
Ceramic,Chip
ECCH0035101
GRM0335C1E1R8C 1.8pF 0.25PF 25V NP0 -
55TO+125C 0603 R/TP 0.3+-0.03 MURATA
MANUFACTURING CO.,LTD.
6 R204 Resistor,Chip ERHZ0000401
MCR01MZSJ000 0OHM 5% 1/16W 1005 R/TP -
ROHM.
6
C22124
C22125
C23050
C6003
C6004
C6005
Capacitor
Ceramic,Chip
EAE62726601
CL03A225MQ3CRNC 2.2uF -20TO20% 6.3V X5R -
55TO+85C 0603 R/TP 0.3T - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 U1100 IC,Charger EAN62670301
BQ51051BYFPR up to 20V adj 0W CSP R/TP 28P -
TEXAS INSTRUMENTS INCO.
6
C15011
C23028
C23031
C23032
C24006
C24007
Capacitor
Ceramic,Chip
EAE62682501
CL21A476MQMNRNR 47uF 20% 6.3V X5R -
55TO+85C 2012 R/TP 1.25T max. SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
C1271
C9022
C9023
Capacitor
Ceramic,Chip
ECZH0025911
GRM0335C1E120J 12pF 5% 25V C0G -
55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
