12. EXPLODED VIEW & REPLACEMENT PART LIST
- 287 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
D202
D203
D204
ZD200
ZD201
ZD202
ZD205
Diode,TVS EAH61693001
uClamp0541Z 5V 6V min 12V 2A 30W
SLP0603P2X3 R/TP 2P 1 SEMTECH
INTERNATIONAL AG
6 C1101
Capacitor
Ceramic,Chip
EAE62685301
CL05A105KA5NQNC 1uF 10% 25V X5R -
55TO+85C 1005 R/TP 0.6T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
C5005
C5013
Capacitor
Ceramic,Chip
ECCH0007804
CL05A225MP5NSNC 2.2uF 20% 10V X5R -
55TO+85C 1005 R/TP 0.5MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 FL11014 Filter,Duplexer EAM62510901
B8553 881.5 869 to 894 836.5 824 to 849 2.5 2.3
2.0x1.6x0.47 DUAL SMD R/TP 9P EPCOS PTE
LTD.
6 X9001 Crystal EAW61823601
1ZCB26000AB0M 26MHZ 10PPM 11F 0 SMD ST
DAISHINKU CORPORATION.
6
D13001
D21001
Diode,Schottky EAH61794001
KDR720F 350mV 30V 100mA 5NSEC 12pF
100mW TFSC R/TP 2P 1 KEC CORPORAITION
6 R15002 Resistor,Chip ERHY0009536
MCR006YZPF1003 100KOHM 1% 1/20W 0603
R/TP - ROHM.
6
C1104
C1113
C1213
Capacitor
Ceramic,Chip
EAE62685701
GRM155R71H103KA88D 10nF 10% 50V X7R -
55TO+125C 1005 R/TP 0.55T max. - MURATA
MANUFACTURING CO.,LTD.
6
R15007
R23018
Resistor,Chip ERHZ0000204
MCR01MZP5F1003 100KOHM 1% 1/16W 1005
R/TP - ROHM.
6
C11097
C23003
C23004
C23007
C24001
C24002
C24008
C24009
Capacitor
TA,Conformal
EAE62748301
F981A226MMALZT 22uF 20% 10V 11UA -
55TO+125C 8OHM 1.6X0.85X0.8MM NONE SMD
R/TP 0.9T max. NICHICON CORPORATION
6
R13001
R13004
R21020
R21021
R21022
R21023
R21024
Resistor,Chip EBC61856201
RC0201FR-07240RL 240OHM 1% 1/20W 0603
R/TP - YAGEO CORPORATION
