12. EXPLODED VIEW & REPLACEMENT PART LIST
- 288 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C11027
C11029
C11044
C11046
C11120
C11122
Capacitor
Ceramic,Chip
EAE62422601
CL02B331KP2NNNC 330pF 10% 10V X7R -
55TO+125C 0402 R/TP 0.22T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
L15005
L23003
L23005
Inductor,Wire
Wound,Chip
EAP62266601
MAMK2520T2R2M 2.2UH 20% - 2A 2 2.2 0.09OHM
- - SHIELD 2.5X2.0X1.2MM - R/TP TAIYO YUDEN
CO.,LTD
6 X23001 Oscillator,TCXO EAW61843801
X1G003851000200 19.2MHZ 1.5PPM 1.8V
2.5x2.0x0.9MM none SMD R/TP EPSON
TOYOCOM CORP
6 C23016
Capacitor
Ceramic,Chip
ECZH0003503
GRM188R61E105K 1uF 10% 25V X5R -55TO+85C
1608 R/TP - MURATA MANUFACTURING
CO.,LTD.
6 U24001 IC,PMIC EAN62416801
PM8821 2.5 to 4.5V adj 0W WLCSP R/TP 42P -
QUALCOMM INCORPORATED.
6 L23004
Inductor,Wire
Wound,Chip
EAP62045901
VLS2012ET-R47N 470NH 30% - 2A 2.05 2
0.059OHM - - SHIELD 2.0X2.0X1.2MM NONE R/TP
TDK KOREA COOPERATION
6 C7001
Capacitor
TA,Conformal
ECTH0002002
F981A336MSA 33uF 20% 10V 3.3UA -55TO+125C
6OHM 2.0X1.25X0.8MM NONE SMD R/TP 0.9T
max. NICHICON CORPORATION, EAST JAPAN
SALES OFFICE
6
C11033
C1214
C1215
C1216
C6020
L11079
Capacitor
Ceramic,Chip
ECCH0009103
C0603C0G1H101JT00NN 100pF 5% 50V C0G -
55TO+125C 0603 R/TP - TDK CORPORATION
6 R13003 Resistor,Chip EBC61996701
MCR004YZPJ202 2KOHM 5% 1/32W 0402 R/TP -
ROHM CO.,LTD.
6 FL11003 Filter,Duplexer EAM62510801
B8563 2132.5 2112.4 to 2152.6 1732.5 1712.2 to
1752.6 2.1 1.8 2.0x1.6x0.47 DUAL SMD R/TP 9P
EPCOS PTE LTD.
6 U11004 IC,Power Amplifier EAN62352501
ACPM-5702-TR1 3.2V to 4.2V 0 0 0W 0W 0 1 SMD
R/TP 10P LTE Band2, 2mode, with CPL, 3*3*0.9,
low current at high power mode AVAGO
TECHNOLOGIES INTERNATIONAL SALES PTE.
LIMITED
