12. EXPLODED VIEW & REPLACEMENT PART LIST
- 289 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
L10002
L10004
Inductor,Wire
Wound,Chip
ELCH0003806
LQW18AN82NG00D 82NH 2% - 250mA 0.6OHM
2KHZ 34 NON SHIELD 1.6X0.8X0.8MM - R/TP
MURATA MANUFACTURING CO.,LTD.
6 L11028
Capacitor
Ceramic,Chip
ECCH0042005
GRM0335C1E8R2BD01D 8.2pF 0.1PF 25V C0G -
55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6
C1102
C1116
Capacitor
Ceramic,Chip
EAE62685601
GRM155R71H223KA12D 22nF 10% 50V X7R -
55TO+125C 1005 R/TP 0.55T max. MURATA
MANUFACTURING CO.,LTD.
6
C11056
C11057
C11112
C7006
C7012
L11040
Capacitor
Ceramic,Chip
ECZH0025916
GRM0335C1E330J 33pF 5% 25V NP0 -
55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 R1204 Resistor,Chip EBC62115901
RC0603J680CS 68OHM 5% 1/20W 0603 R/TP -
SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 U13001
IC,Digital
Baseband
Processor,4G
EAN62417801
MDM9215M 383 NSP, 28nm,MDM9215M,Slim
Modem, on-chip LPDDR1 , LTE/HSPA,GPS NSP
R/TP 383P QUALCOMM INCORPORATED.
6
C15003
C9032
Capacitor
Ceramic,Chip
EAE62282201
GRM033R71E102KA01D 0.000000001F 10% 25V
X7R -55TO+125C 0603 R/TP 0.3+/-0.03 MM -
MURATA MANUFACTURING CO.,LTD.
6
R1101
R21018
R7013
Resistor,Chip ERHY0009303
MCR006YZPF1002 10KOHM 1% 1/20W 0603 R/TP
- ROHM.
6 R1116 Resistor,Chip EBC62316201
RC0603F224CS 220KOHM 1% 1/20W 0603 R/TP -
SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 C11036
Capacitor
Ceramic,Chip
EAE62683501
C1005NPO508BGTQ 0.5pF 0.1PF 50V C0G -
55TO+125C 1005 R/TP 0.55T max. DARFON
ELECTRONICS CORP.
6 X21001 Crystal EAW61543401
1ZCB27000AA0A 27MHZ 10PPM 12F ; SMD R/TP
DAISHINKU CORPORATION.
6 U15001 IC,PMIC EAN62409301
PM8018 2.5 to 5.5V adj 0W BGA R/TP 105P -
QUALCOMM INCORPORATED.
6 U6003
IC,DC,DC
Converter
EAN62186901
LM3530TMX-40 NOPB 2.7 to 5.5V adj 0W CSP
R/TP 12P - NATIONAL SEMICONDUCOTR
CORPORATION.
