12. EXPLODED VIEW & REPLACEMENT PART LIST
- 290 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
R13011
R9006
Resistor,Chip ERHY0009302
MCR006YZPF1001 1KOHM 1% 1/20W 0603 R/TP -
ROHM.
6
C11028
C11030
C11119
C11121
C7008
Capacitor
Ceramic,Chip
EAE62962301
GRM155R61A225KE95 2.2uF -10TO+10% 10V
X5R -55TO+85C 1005 R/TP 0.5 L:1.0+-0.05
W:0.5+-0.05 T:0.5+-0.05 MURATA
MANUFACTURING CO.,LTD.
6 C11125
Inductor
Multilayer,Chip
EAP62227501
LG HK 0603 5N6S-T 5.6NH 0.3NH - 260mA - -
0.36OHM 4.6GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6 U5002
IC,Speaker
Amplifier
EAN62206801
TPA2028D1 2.5~5.5V 999W WCSP R/TP 9P I2C
I/F, ClassD TEXAS INSTRUMENTS KOREA LTD,
HONGKONG BRANCH.
6
C15016
C23062
Capacitor
Ceramic,Chip
ECCH0000143
MCH155CN102KK 1nF 10% 50V X7R -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
6 ZD7004 Diode,TVS EDTY0012102
PESD5V0V1BL 5V 5.8V min. 12.5V 4.8A 45W
SOD-882 R/TP 2P 1 STC CORP.
6 C23005
Capacitor
Ceramic,Chip
ECCH0007802
CL10A475KP8NNNC 4.7uF 10% 10V X5R -
55TO+85C 1608 R/TP - - SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6 R23013 Resistor,Chip ERHY0009504
MCR006YZPJ102 1KOHM 5% 1/20W 0603 R/TP -
ROHM.
6 C6019
Capacitor
Ceramic,Chip
EAE62505701
CL10A105KB8NNNC 1uF 10% 50V X5R -
55TO+85C 1608 R/TP 0.9T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
R9001
R9002
R9010
Resistor,Chip ERHY0009526
MCR006YZPJ472 4.7KOHM 5% 1/20W 0603 R/TP
- ROHM.
6
PT15001
PT23001
Thermistor,NTC SETY0007301
NCP15WF104F03RC NTC,100000
ohm,SMD,4250K+/-1%,100K,1%,0.1mA,4250K+/-
1%,SMD,R/TP MURATA MANUFACTURING
CO.,LTD.
6 C5012
Capacitor
Ceramic,Chip
ECZH0003103
GRM36X7R104K10PT 100nF 10% 10V X7R -
55TO+125C 1005 R/TP - MURATA
MANUFACTURING CO.,LTD.
6
R1205
R1206
Resistor,Chip ERHY0009301
MCR006YZPF1000 100OHM 1% 1/20W 0603 R/TP
- ROHM.
