12. EXPLODED VIEW & REPLACEMENT PART LIST
- 291 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C5002
C5004
Capacitor
Ceramic,Chip
ECCH0042004
GRM033R61A562KA01D 5.6nF 10% 10V X5R -
55TO+85C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 C7002
Capacitor
Ceramic,Chip
EAE62442101
GRM022R61A103KE19L 10nF 10% 10V X5R -
55TO+85C 0402 R/TP 0.22T max. MURATA
MANUFACTURING CO.,LTD.
6
R21007
R21008
Resistor,Chip EBC61997301
MCR004YZPF4701 4.7KOHM 1% 1/32W 0402
R/TP - ROHM CO.,LTD.
6 L11029
Inductor
Multilayer,Chip
EAP62226201
LQP03TG4N7J02D 4.7NH 5% - 250mA - -
0.72OHM 6GHZ 12 SHIELD - 0.6X0.3X0.3MM R/TP
MURATA MANUFACTURING CO.,LTD.
6
C21005
C21006
Capacitor
Ceramic,Chip
ECCH0009504
MCH032A180JK 18pF 5% 25V NP0 -55TO+125C
0603 R/TP - ROHM.
6
FB5001
FB5002
Filter,Bead EAM62071101
BLM15PD121SN1D 120 ohm 1.0X0.5X0.5 25%
0.09 ohm 1.3A SMD R/TP 2P 0 MURATA
MANUFACTURING CO.,LTD.
6 D7003 Diode,TVS EAH61794301
ESD5205P6T6G 5V 5.5V min. 10V 2UA 0W SOT-
963 R/TP 6P 5 ON SEMICONDUCTOR
6 C212
Capacitor
Ceramic,Chip
ECZH0000813
C1005C0G1H101JT 100pF 5% 50V C0G -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 X15001 Crystal EAW61883401
X1E0002910001 19.2MHZ 10PPM 7F - SMD R/TP
EPSON TOYOCOM CORP
6 FL11004 Filter,Saw EAM62290401
B9489 1747.5 1.4*1.1*0.4 SMD R/TP 5P EPCOS
PTE LTD.
6
R21012
R21016
R21030
R6013
Resistor,Chip ERHY0009505
MCR006YZPJ103 10KOHM 5% 1/20W 0603 R/TP -
ROHM.
6 C7009
Capacitor
Ceramic,Chip
ECCH0000151
CL05B472KB5NNNC 4.7nF 10% 25V X7R -
55TO+125C 1005 R/TP - - SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6 U11002 IC,Power Amplifier EAN62397201
ACPM-5704-TR1 3.2V to 4.2V 0 0 0W 0W 0 1 SMD
R/TP 10P LTE Band4, 2mode, with CPL, low current
at high power mode, 3*3*0.9 AVAGO
TECHNOLOGIES INTERNATIONAL SALES PTE.
LIMITED
6 C1107
Capacitor
Ceramic,Chip
ECCH0000146
MCH155C182K 1.8nF 10% 50V X7R -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
