12. EXPLODED VIEW & REPLACEMENT PART LIST
- 292 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 C11034
Capacitor
Ceramic,Chip
ECCH0009506
MCH032A270JK 27pF 5% 25V NP0 -55TO+125C
0603 R/TP - ROHM.
6
C1103
C1115
Capacitor
Ceramic,Chip
EAE62685501
GRM188R71E474KA12D 0.47uF 10% 25V X7R -
55TO+125C 1608 R/TP-T 0.9T max. - MURATA
MANUFACTURING CO.,LTD.
6 C9035
Capacitor
Ceramic,Chip
ECZH0025920
GRM033R71C102K 1nF 10% 16V X7R -
55TO+125C 0603 R/TP - - MURATA
MANUFACTURING CO.,LTD.
6 L11026
Inductor
Multilayer,Chip
ELCH0004709
1005GC2T3N3SLF 3.3NH 0.3NH - 300mA
0.19OHM 4.5GHZ 8 SHIELD NONE
1.0X0.5X0.5MM R/TP PILKOR ELECTRONICS
LTD.
6
C1111
C1112
Capacitor
Ceramic,Chip
EAE62843001
CL10A106MO8NQNC 10uF -20TO20% 16V X5R -
55TO+85C 1608 R/TP 0.8+-0.15 - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 L11025
Capacitor
Ceramic,Chip
ECZH0000841
C1005C0G1H560JT000F 56pF 5% 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 U5001 IC,Audio Codec EAN62155601
WCD9310 1.14~4.5V 999W NSP R/TP 71P QCT
CODEC QUALCOMM INCORPORATED.
6 D6001 Diode,Switching EDSY0017701
SDB1040 550mV 40V 1A 30A 0SEC 0W SOD123
R/TP 2P 1 AUK CORP
6 R4010 Resistor,Chip ERHY0009502
MCR006YZPJ100 10OHM 5% 1/20W 0603 R/TP -
ROHM.
6 U21001
IC,Digital
Baseband
Processor,4G
EAN62446801
APQ8064 Quad 1.5G Krait, 1080p, 200M tri/sec
BGA R/TP 839P QUALCOMM INCORPORATED.
6
C13004
C9034
Capacitor
Ceramic,Chip
ECCH0009106
C0603X7R1C103KT 10nF 10% 10V X7R -
55TO+125C 0603 R/TP - TDK CORPORATION
6 C23021
Capacitor
Ceramic,Chip
EAE62686001
CL05A475MO5NUNC 4.7uF 20% 16V X5R -
55TO+85C 1005 R/TP 0.7T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 CN6002 Connector,BtoB ENBY0039601
GB042-20S-H10-E3000 20P 0.4MM STRAIGHT
SOCKET SMD R/TP 1M - LS Mtron Ltd.
6 R1114 Resistor,Chip EBC62236701
RC0402FR-074K75L 4.75KOHM 1% 1/16W 1005
R/TP 0.4T max. YAGEO CORPORATION
