12. EXPLODED VIEW & REPLACEMENT PART LIST
- 293 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 SUMY00
Microphone
Condenser
SUMY0010609
SPU0410HR5H -PB SPU0410HR5H -PB
SPU0410HR5H -PB,UNIT ,-42 dB,3.76*2.95*1.1
,mems smd mic KNOWLES ACOUSTICS
KNOWLES ACOUSTICS
6 C11124
Capacitor
Ceramic,Chip
ECCH0009209
GRM0335C1E1R0C 1pF 0.25PF 25V X7R -
55TO+125C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 L11045
Inductor
Multilayer,Chip
EAP62227601
LG HK 0603 6N8J-T 6.8NH 5% - 250mA - -
0.39OHM 3.9GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6 C9029
Capacitor
Ceramic,Chip
EAE62944801
GRM155R60J334K 330nF -10TO+10% 6.3V X5R -
55TO+85C 1005 R/TP 0.5T L:1.0+-0.05 W:0.5+-
0.05 T:0.5+-0.05 MURATA MANUFACTURING
CO.,LTD.
6
C5021
C5022
Capacitor
Ceramic,Chip
EAE62422701
CL02C330JO2ANNC 33pF 5% 16V C0G -
55TO+125C 0402 R/TP 0.22T max. SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 C23020
Capacitor
Ceramic,Chip
ECZH0004402
CL05F104ZO5NNNC 0.1uF -20TO+80% 16V Y5V -
30TO+85C 1005 R/TP - - SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6 U7002 IC,Load Switch EAN62403501
FPF1039BUCX 1.2 to 5.5V 4.4SEC 32SEC 1.2W
CSP R/TP 6P Load Switch FAIRCHILD
SEMICONDUCTOR
6 R21035 Resistor,Chip EBC61976201
MCR004YZPF4641 4.64KOHM 1% 1/32W 0402
R/TP - ROHM CO.,LTD.
6 FL200 Filter,EMI/Power SFEY0015301
NFM18PC104R1C3 ESD/EMI 0HZ 0.1uF 0H SMD
R/TP MURATA MANUFACTURING CO.,LTD.
6 C1114
Capacitor
Ceramic,Chip
ECZH0001215
C1005X5R1A105KT000F 1uF 10% 10V X5R -
55TO+85C 1005 R/TP - TDK KOREA
COOPERATION
6 L6004
Inductor,Wire
Wound,Chip
EAP61747901
VLS3010ET-100M 10UH 20% - 560mA 0.56 0.8
0.468OHM - - SHIELD 3.0X3.0X1.0 MM NONE
R/TP TDK KOREA COOPERATION
6 X23002 Crystal EAW61843401
Q13FC1350000200 32.768KHZ 20PPM
0.000000000007F NONE SMD R/TP EPSON
TOYOCOM CORP
6
C23014
C6001
Capacitor
Ceramic,Chip
ECCH0007803
CL10A106MP8NNNC 10uF 20% 10V X5R -
55TO+85C 1608 R/TP 0.8MM SAMSUNG
ELECTRO-MECHANICS CO., LTD.
