12. EXPLODED VIEW & REPLACEMENT PART LIST
- 296 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 R1116 Resistor,Chip EBC62316201
RC0603F224CS 220KOHM 1% 1/20W 0603 R/TP -
SAMSUNG ELECTRO-MECHANICS CO., LTD.
6 L11059
Inductor
Multilayer,Chip
EAP62245901
LG HK 0603 2N7S-T 2.7NH 0.3NH - 340mA - -
0.21OHM 7.7GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6
FB10001
FB10002
FB10003
FB10004
Filter,Bead SFBH0008102
BLM15HD182SN1D 1800 ohm 1.0X0.5X0.5 25%
2.2 ohm 0.2A SMD R/TP 2P 0 MURATA
MANUFACTURING CO.,LTD.
6
D202
D203
D204
ZD200
ZD201
ZD202
ZD205
Diode,TVS EAH61693001
uClamp0541Z 5V 6V min 12V 2A 30W
SLP0603P2X3 R/TP 2P 1 SEMTECH
INTERNATIONAL AG
