12. EXPLODED VIEW & REPLACEMENT PART LIST
- 295 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C10006
C10007
Capacitor
Ceramic,Chip
ECCH0009230
GRM033R61A222K 2.2nF 10% 25V X5R -
55TO+85C 0603 R/TP - MURATA
MANUFACTURING CO.,LTD.
6 C10009
Capacitor
Ceramic,Chip
ECCH0009207
GRM033R71A682K 6.8nF 10% 10V X7R -
55TO+125C 0603 R/TP - - MURATA
MANUFACTURING CO.,LTD.
6
C9017
C9020
Capacitor
Ceramic,Chip
ECCH0000118
MCH155A300J 30pF 5% 50V NP0 -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
6 U10002 IC,Analog Switch EUSY0186502
FSA4157L6X_F113 1.65~5.5 50SEC 20SEC 0W
MICROPAK R/TP 6P 1 FAIRCHILD
SEMICONDUCTOR
6 SW11001 Connector,RF ENWY0008701
MS-156C NONE STRAIGHT SOCKET SMD
T/REEL AU 50OHM 400mDB HIROSE KOREA
CO.,LTD
6 U10000 IC,Analog Switch EAN62651701
FSA2269UMX 1.65~4.5V 70NSEC 40NSEC 999W
MLP R/TP 10P Negative Swing FAIRCHILD
SEMICONDUCTOR HONG KONG LTD.
6 ZD10003 Diode,TVS EAH61872601
PESD12VS1UA 12V 13.3V min. 19V 22.5A 360mW
SOD323 R/TP 2P 1 NXP Semiconductors
6 L1206
Capacitor
Ceramic,Chip
ECZH0000802
C1005C0G1H010CT 1pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 C1205
Capacitor
Ceramic,Chip
ECCH0042007
GRM0335C1E6R8BD01D 6.8
pF,25V,B,C0G,TC,0603,R/TP,0.0000000000068,0.
1PF,25V,C0G,-55TO+125C,0603,R/TP,0.3 mm
MURATA MANUFACTURING CO.,LTD.
6 ZD6002 Diode,TVS EDTY0012501
UCLAMP3311T.TCT 3.3V 3.5V min. 6.5V 5A -
SLP1006P2T R/TP 2P 1 SEMTECH
CORPORATION
6
ZD10007
ZD10008
Diode,TVS EDTY0012101
PESD5V0F1BL 5.5V 6V min 11V 2.5A - SOD-882
R/TP 2P 1 STC CORP.
6
C204
C205
Capacitor
Ceramic,Chip
ECCH0009104
C0603C0G1H330JT00NN 33pF 5% 50V C0G -
55TO+125C 0603 R/TP - TDK CORPORATION
6
C9014
C9015
Capacitor
Ceramic,Chip
ECCH0000122
MCH155A470JK 47pF 5% 50V NP0 -55TO+125C
1005 R/TP - ROHM Semiconductor KOREA
CORPORATION
