12. EXPLODED VIEW & REPLACEMENT PART LIST
- 300 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 R4001 Resistor,Chip EBC61995801
MCR004YZPJ103 10KOHM 5% 1/32W 0402 R/TP -
ROHM CO.,LTD.
6
R21012
R21016
R21030
R6013
Resistor,Chip ERHY0009505
MCR006YZPJ103 10KOHM 5% 1/20W 0603 R/TP -
ROHM.
6
R6004
R6014
Resistor,Chip ERHZ0000405
MCR01MZP5J103 10KOHM 5% 1/16W 1005 R/TP
- ROHM.
6
FL6001
FL6005
Filter,EMI/Power EAM62291101
ACFE1A2G900E COMMON MODE NOISE FILTER
0HZ 0F 0H SMD R/TP - AMOTECH CO., LTD.
6
L10002
L10004
Inductor,Wire
Wound,Chip
ELCH0003806
LQW18AN82NG00D 82NH 2% - 250mA 0.6OHM
2KHZ 34 NON SHIELD 1.6X0.8X0.8MM - R/TP
MURATA MANUFACTURING CO.,LTD.
6
L11002
L11011
L11012
L11015
L11019
L1201
L1208
Inductor
Multilayer,Chip
EAP62246201
LG HK 0603 10NJ-T 10NH 5% - 220mA - -
0.51OHM 2.9GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6
FB6001
FB6002
FB6003
FB6004
Filter,Bead SFBH0008101
BLM15AG601SN1D 600 ohm 1.0X0.5X0.5 25% 0.6
ohm 0.3A SMD R/TP 2P 0 MURATA
MANUFACTURING CO.,LTD.
6
R10015
R10018
Resistor,Chip EBC62496201
RK73H1FTQTBL4701F 4.7KOHM 1% 1/32W 0402
R/TP - KOA CORPORATION.
6 U8002 IC,Gyro Sensor EAN62409401
MPU-6050 Accelerometer embedded Gyro Sensor
4X4 QFN R/TP 24P One Chip Solution
INVENSENSE
6 L11067
Inductor
Multilayer,Chip
EAP62227401
LG HK 0603 3N9S-T 3.9NH 0.3NH - 300mA - -
0.27OHM 6GHZ 5 SHIELD - 0.6X0.3X0.3MM R/TP
TAIYO YUDEN CO.,LTD
6
C21007
C22057
C22058
C22095
C23045
C23054
C23060
C23061
C5016
C5017
Capacitor
Ceramic,Chip
ECCH0000198
CL05A225MQ5NSNC 2.2uF 20% 6.3V X5R -
55TO+85C 1005 R/TP . SAMSUNG ELECTRO-
MECHANICS CO., LTD.
