12. EXPLODED VIEW & REPLACEMENT PART LIST
- 301 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6 C209
Capacitor
Ceramic,Chip
ECCH0001001
C1005C0G1H6R8CT000F 6.8pF 0.25PF 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6
R6036
R7031
Resistor,Chip ERHY0009554
MCR006YZPF2002 20KOHM 1% 1/20W 0603 R/TP
- ROHM.
6
VA11001
VA1201
Varistor EAF61650701
LXES15AAA1-117 15V 25% 0.1pF 1.0X0.5X0.33
mm IEC61000-4-2 (ESD) level #4 SMD R/TP
MURATA MANUFACTURING CO.,LTD.
6
C11033
C1214
C1215
C1216
C6020
L11079
Capacitor
Ceramic,Chip
ECCH0009103
C0603C0G1H101JT00NN 100pF 5% 50V C0G -
55TO+125C 0603 R/TP - TDK CORPORATION
6
C11084
C11088
C11093
C11105
Capacitor
Ceramic,Chip
ECZH0000830
C1005C0G1H330JT000F 33pF 5% 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6 R6037 Resistor,Chip ERHY0009506
MCR006YZPJ104 100KOHM 5% 1/20W 0603 R/TP
- ROHM.
6
R4002
R4003
R4004
R4005
R4006
R4007
R4008
R4009
Resistor,Chip EBC61996301
MCR004YZPF4702 47KOHM 1% 1/32W 0402 R/TP
- ROHM CO.,LTD.
