12. EXPLODED VIEW & REPLACEMENT PART LIST
- 302 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
R1102
R1103
R13002
R14006
R14007
R15005
R21015
R22001
R23011
R23017
R23019
R23021
R5001
R5002
R5003
R5004
R6030
R7017
R9008
R9009
PCB ASSY,MAIN
PAD SHORT
SAFP0000401 LG-LU3000 LGTBK,MAIN,A,
6 C202
Capacitor
Ceramic,Chip
EAE62286801
CL03A104KP3NNNC 0.0000001F 10% 10V X5R -
55TO+85C 0603 R/TP 0.3 - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
R13011
R9006
Resistor,Chip ERHY0009302
MCR006YZPF1001 1KOHM 1% 1/20W 0603 R/TP -
ROHM.
6 FL11011 Filter,Saw SFSY0037501
SAFEB897MAM0F00 897.5MHz 1.4*1.1*0.6 SMD
R/TP 5P MURATA MANUFACTURING CO.,LTD.
6 C6002
Capacitor
Ceramic,Chip
ECCH0005604
GRM188R60J106M 10000000
pF,6.3V,M,X5R,TC,1608,R/TP,0.8 mm MURATA
MANUFACTURING CO.,LTD.
6
C5006
C5010
C5018
C9031
Capacitor
Ceramic,Chip
EAE62762301
CL03A105MP3NSNC 1uF 20% 10V X5R -
55TO+85C 0603 R/TP 0.33 MM - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6
L11004
L11063
Inductor
Multilayer,Chip
EAP62246001
LG HK 0603 3N3S-T 3.3NH 0.3NH - 320mA - -
0.23OHM 6.7GHZ 5 SHIELD - 0.6X0.3X0.3MM
R/TP TAIYO YUDEN CO.,LTD
6 CN6004 Connector,BtoB ENBY0051001
GB042-10S-H10-E3000 10P 0.4MM STRAIGHT
FEMALE SMD R/TP 1M - LS Mtron Ltd.
6 C6037
Capacitor
Ceramic,Chip
ECCH0004904
GRM155R60J105K 1uF 10% 6.3V X5R -55TO+85C
1005 R/TP - MURATA MANUFACTURING
CO.,LTD.
