12. EXPLODED VIEW & REPLACEMENT PART LIST
- 303 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C12005
C12007
Capacitor
Ceramic,Chip
ECCH0006201
C1608X5R0J475KT000N 4.7uF 10% 6.3V X5R -
55TO+85C 1608 R/TP - TDK CORPORATION
6
L10001
L10003
Inductor
Multilayer,Chip
ELCH0003841
LQG15HS82NJ02D 82NH 5% - 150mA 1.2OHM
700MHZ 8 SHIELD NONE 1.0X0.5X0.5MM R/TP
MURATA MANUFACTURING CO.,LTD.
6
C1222
L1223
L1231
Inductor
Multilayer,Chip
EAP62186301
LQP03TG1N8C02D 1.8NH 0.2NH - 500mA - -
0.2OHM 6GHZ 13 SHIELD - 0.6X0.3X0.3MM R/TP
MURATA MANUFACTURING CO.,LTD.
6
C1202
L1210
Inductor
Multilayer,Chip
EAP62108001
LQP03TG2N2C02D 2.2NH 0.2NH - 450mA - -
0.25OHM 6GHZ 13 SHIELD - 0.6X0.3X0.3MM R/TP
MURATA MANUFACTURING CO.,LTD.
6
C11096
C11103
C11104
Capacitor
Ceramic,Chip
EAE62422001
RM LMK042 B7102KC-FW 1nF 10% 10V X7R -
55TO+125C 0402 R/TP 0.22T max. TAIYO YUDEN
CO.,LTD
6
C1221
L11001
L11010
L1237
Inductor
Multilayer,Chip
EAP62226901
LG HK 0603 1N0S-T 1NH 0.3NH - 470mA - -
0.11OHM 10GHZ 4 SHIELD - 0.6X0.3X0.3MM R/TP
TAIYO YUDEN CO.,LTD
6 C1101
Capacitor
Ceramic,Chip
EAE62685301
CL05A105KA5NQNC 1uF 10% 25V X5R -
55TO+85C 1005 R/TP 0.6T max. - SAMSUNG
ELECTRO-MECHANICS CO., LTD.
6 Q23001 FET EBK61892201
KTK5132V N-CHANNEL MOSFET 30V +-20 100mA
7OHM 100mW VSM R/TP 3P KEC
CORPORAITION
6 FL1200 Filter,Saw SFSY0042901
SAFEA1G58KA0F00 1575.42M/1602M 1.4*1.1*0.5
SMD R/TP 5P MURATA MANUFACTURING
CO.,LTD.
6 U4002 IC,MCP,eMMC EAN62512301
THGBM5G7A2JBAIR 16GBYTE
2.7VTO3.6V,1.7VTO1.95V 11.5x13.0x1.0 TR 153P
MLC NAND FBGA 16GB eMMC v4.41 (19nm 64Gb
MLC x 2, 11.5x13.0x1.0) TOSHIBA ELECTRONICS
KOREA CORPORATION
6
C21003
C5003
C7018
Capacitor
Ceramic,Chip
EAE62461701
RM JMK042 BJ104MC-FW 100nF 20% 6.3V X5R -
55TO+85C 0402 R/TP 0.22T max. TAIYO YUDEN
CO.,LTD
