12. EXPLODED VIEW & REPLACEMENT PART LIST
- 304 -
Copyright © 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Level LocationNo. Description PartNumber Spec Remark
6
C11037
C11038
C11039
C11063
C11064
C11065
C11116
C11117
C11118
Capacitor
Ceramic,Chip
EAE62422201
RM EMK042 CG101JC-FW 100pF 5% 16V C0G -
55TO+125C 0402 R/TP 0.22T max. TAIYO YUDEN
CO.,LTD
6
C1232
C1233
C1235
C1236
Capacitor
Ceramic,Chip
ECCH0009105
C0603C0G1H820JT00NN 82pF 5% 50V NP0 -
55TO+125C 0603 R/TP - - TDK CORPORATION
6
R21031
R21032
R21033
R21034
Resistor,Chip EBC61976101
MCR004YZPF2400 240OHM 1% 1/32W 0402 R/TP
- ROHM CO.,LTD.
6
C9016
C9019
Capacitor
Ceramic,Chip
ECCH0001002
C1005C0G1H181JT000F 180pF 5% 50V NP0 -
55TO+125C 1005 R/TP - TDK KOREA
COOPERATION
6
C11045
C11047
C15009
C23001
C23008
C23009
C23010
C23011
C23017
C23056
C9027
C9030
C9033
Capacitor
Ceramic,Chip
EAE62506501
CL05A475MP5NRNC 4.7uF 20% 10V X5R -
55TO+85C 1005 R/TP - - SAMSUNG ELECTRO-
MECHANICS CO., LTD.
6
VA6001
VA6002
VA6003
VA6004
Varistor SEVY0010501
IECS0505C040FR 10V 0% 4E-12F 1.0x0.5x0.3
IEC61000-4-1 (ESD) level #4 SMD R/TP
INNOCHIPS TECHNOLOGY
6 X21001 Crystal EAW61543401
1ZCB27000AA0A 27MHZ 10PPM 12F ; SMD R/TP
DAISHINKU CORPORATION.
6 U6004 IC,Signal Bridge EAN62533101
ANX7808BH-BA-R HDMI to DP tx, 4.5X4.5 VFBGA
R/TP 49P ANALOGIX SEMICONDUCTOR
6
R6015
R6022
Resistor,Chip EBC62296301
RC0201FR-07665KL 665KOHM 1% 1/20W 0603
R/TP 0.26T max. YAGEO CORPORATION
